TROUBLESHOOTING About

Cubiscan 325 67

MDMI

This field displays the Multiple Dimensional Measuring Instrument (MDMI)

status. This status can either be sealed or unsealed.

NAWI

This field displays the Non-Automatic Weighing Instrument (NAWI) status.

This status can either be sealed or unsealed.

Main

This field displays the firmware version used for the main controller.

FPGA

This field displays the firmware version used for the FPGA.

Kernel

This field displays the firmware version used for the kernel.

Scale

This field displays the firmware version used for the scale.

W1, W2

H1, H2

These fields display the firmware used for the width 1 and 2 boards, as well

as the height 1 and 2 boards.

Config-Audit

This section discusses the Config-Audit menu. Complete the following

steps to access the Config-Audit menu.

1. Tap MENU at the home screen.

Figure 61

Home screen
