SETUP Connecting to a computer or network (optional)

Cubiscan 325 18

Installing and configuring the Ethernet driver

To install the Ethernet driver there are two options.

1. You can install the driver using the TRENDnet CD-ROM and User’s

Guide.

Or you can complete the following steps:

1. Plug the white TRENDnet USB to Ethernet adapter into the computer.

The following bubble will appear in the bottom right corner of the

screen.

• Wait a few moments for the installation process to finish and the

following bubble will pop up.

• If you clicked on the installation bubble, the following window will open.

Figure 15

Installation bubble

Figure 16

Device installed bubble

Figure 17

Installation process bubble
