TROUBLESHOOTING Diagnostics

Cubiscan 325 70

Diagnostics

This section describes the diagnostic capabilities of the Cubiscan 325.

Scale diagnostics

Complete the following steps to view the Scale Diagnostics.

1. From the home screen, tap MENU.

NOTE

If you have set up a password previously in the system configuration, you need to

enter the password to unlock the menu. Refer to page 43.

Figure 65

Home screen

Main Page
