Navigating the Menus and Keypad 17
Cat. No. 01021161
Smart Controller Programming
The programming for the Smart Controller is based on a menu structure. There are six top-level menus with additional op-
tions in submenus. The top-level menus are:
1. INFORMATION
2. MANUAL MODE
3. SET DATE/TIME
4. ACCESSORIES
5. ADV. SETUP
6. DIAGNOSTICS
Here is a brief explanation of what you will find under each menu.
Menu/Submenu Description
Information Scrolls through the operating information for the unit.
Manual Mode Initiates a manual regeneration.
Set Time and Date Sets or changes the time and/or date. This is initially done during first time set up.
This information is saved in memory even in the event of a power outage.
Accessories Sets up any installed accessories. This includes Aqua-Sensor
®
, beeper, Aux In, Aux
Outputs, Smart Brine Tank sensor, Wireless Remote, Modem, Chlorinator, flow meter,
service phoneline, and external filter.
Advanced Setup Customizes the unit settings. There are five sub-menus that offer customized settings.
System Setup Customizes many of the initial setup information. Water Hardness, Iron, Salt Type,
Resin Type and Line Pressure are among the settings.
Regeneration Setup Specifies custom salt dosage, reserve capacity, regeneration time and regeneration
mode.
Cycle Times Specifies custom cycle times for the units.
Regeneration Trigger Specifies custom regeneration triggers, the regeneration interval, predict mode and
days of regeneration.
Diagnostics Performs diagnostics for sensors, wireless, progressive flow, motor control, data port,
phone line (modem), and displays advanced statistics.
