72 Culligan® Smart Controller (GBE) for Softeners and Filters
72 Cat. No. 01021161
Manual Cycling
Manual cycling can be performed when the unit is starting either in SERVICE or while it is already within any portion of the
REGENERATION process. If the unit is currently regenerating, the name of the current cycle position and the number of
minutes remaining in the current cycle position will be displayed.
1. From the HOME screen, press to view the main menu.
2. The screen displays the main menu. Press to select
6)DIAGNOSTICS.
3. Press to select 5) MOTOR CONTROL. If control is not in regen-
eration, the screen displays the motor control status.
4. The displayed motor control status may be S, B, E, or F.
S = Service
B = Backwash
E = Brine Draw/Slow Rinse
F = Fast Rinse
5. Press to cycle the control valve all the way around without stopping the motor.
6. Press to move the motor to another position (such as from S to B).
7. If cycling the control during regeneration, the screen displays the remaining time
left for the regeneration setting. Press
or and then to select either
NEXT CYCLE, END REGEN NOW, or END/CANCEL TRIG.
a. Next Cycle will cause the control to move the valve to the next cycle
b. End Regen Now will terminate the regeneration in process and
return the control to service.
c. End/Cancel Trig will end the regeneration process and cancel the
regeneration trigger (such as from the meter or Aqua-Sensor). The
unit will return to service.
8. Press
to accept the new regeneration setting.
9. Press to return to the home screen.
