26 Culligan® Smart Controller (GBE) for Softeners and Filters
26 Cat. No. 01021161
Setting Screen Display Range Changing the Setting
Backwash
Time
0–150
Use this setting to adjust the number of minutes for backwash.
The default setting is 10 minutes. You generally will not need
to change this setting. Press
to view the next setting.
Brine
Draw-
Rinse
0–150
The screen displays the brine draw-rinse setting. For com-
mercial softener applications this value should be 60 minutes.
Press
or and then to extend the time if the brine
is not properly rinsing out within this duration.
Fast Rinse-
Time
0–150
This value is displayed as Fast Rinse-Time for five-cycle
valves and Fill Time for four-cycle valves. The value is calculat-
ed for household units based on input parameters.
For commercial units, press
to keep the default setting of
10 minutes.
Fill Time
0–9000
The screen displays the fill time setting if a 5-cycle valve is
selected, based on the salt dosage. Find this value in the
unit’s installation manual. For example, if you have a Hi-Flo 22
WS-90 water softener (3 ft³) and you want to set a capacity of
60,000 grains, the chart in Appendix A of the Hi-Flo 22 manual
shows a time setting of 12 minutes. For a 4-cycle valve, the
refill is controlled by AUX OUTPUT 2; set the refill time there.
See page 48.
For filters, Press
to keep the default setting, one (1) minute.
NOTE This time is displayed in seconds. For exam-
ple, If you entered 12 minutes during FTS, then
this will display 720 seconds.
5. The cycle times setup is complete. The screen displays the advanced setup menu.
Press
to display the home screen.
Regeneration Triggers Setup
Default values are shown for each selection.
1. From the HOME scrren, press to view the main menu.
2. The screen displays the main menu. Press to select 5)ADV.
SETUP.
3. The screen displays the advanced setup menu. The menu includes SYSTEM SET-
UP, REGEN SETUP, CYCLE TIMES, and REGENTRIGGER.
4. Press to select 4)REGENTRIGGER.
To Next Page
