First Time Set Up 19
Cat. No. 01021161
First Time Set Up
First Time Setup Procedure
If at any time you need to re-run the First Time Setup, refer to the instructions on page 68.
After completing the plumbing connections to the water softener, turn on and program the Smart Controller.
First Time Setup
1. When a new controller is first turned on, the screen displays FIRST TIME SETUP.
Press
to view and change (if necessary) the softener configuration.
2. The screen displays the serial number and firmware version for the Smart Control-
ler. Press
to view the next setting.
NOTE If this unit will be installed with a modem, this electronic ID number
MUST be reported to Culligan on the Web site www.myculligan.com.
3. The screen displays the first date setting for the Smart Controller.
4. Press to change the month setting from the default value. The screen displays
a cursor (>) next to the value.
5. Press to view the next available value (February).
6. Press to accept the new value.
7. The screen displays the default day setting. Press or and then to
change the value.
Set Up Other Values
Use the same procedure to change the values of other Smart Controller settings. After changing the setting, press the
CHECK MARK button to accept the displayed screen value.
Setting Screen Display Range Changing the Setting
Day
1–31
Press
or and then to change the day. The
screen displays the new day (in this example, from 1 to 2).
Year
2008–19
Press
or and then to change the year. The
screen displays the selected year (in this example, 2008).
Clock Type
12 or 24
Press
or and then to change the setting. The
screen displays either 12 or 24.
Hour
12PM–
11AM
Press
or and then to change the hour. The
screen displays the new hour (in this example, 12) with AM or
PM.
