80 Culligan® Smart Controller (GBE) for Softeners and Filters
80 Cat. No. 01021161
5. Press to test the signal strength. The screen displays the number of connection
attempts and the radio signal strength index. If the screen displays RSSI = 0, there
is no wireless signal.
6. Press any button to return to the Diagnostics menu.
Test Progressive Flow
1. From the diagnostics menu, press to select 4)TEST PROGFLOW.
The screen displays the progressive flow test diagnostic.
2. The progressive test screen will show the data packet transmissions from the mas-
ter (Tx) and which slaves are receiving (1, 2, 3, 4, and/or 5). For example, in a tri-
plex system, if the transmission from the master (Tx) is 0085, then you should see
1:0085 and 2:0085. 3, 4, and 5 will remain all zeros because no other slaves are
connected.
3. Press any key to return to the Diagnostics menu.
Motor Control Diagnostic
1. From the diagnostics menu, press to select 5)MOTOR CON-
TROL. The screen displays the motor control diagnostic.
2. The screen displays the position of the motor. Press to change the motor posi-
tion and then return to the Diagnostics menu. See “Manual Cycling” on page 72 for
more information.
Aux Out Status
1. From the Diagnostics menu, press to select 6)AUX OUT
STAT. The screen displays the AUX OUT STATUS settings.
2. The screen displays the status of each of the controller’s AUX Outputs. Press any
key to return to the Diagnostics menu.
Aux Out Test
1. From the Diagnostics menu, press to select 7)AUX OUT
TEST.
