Customizing Set Up 23
Cat. No. 01021161
Other System Setup Values
Use the same procedure to change the values of other Smart Controller settings. Press the DOWN ARROW button to
scroll through the settings, unless otherwise instructed. After changing the setting, press the CHECK MARK button to ac-
cept the displayed screen value. The Smart Controller will display the next system setting from the menu.
NOTE All system setup settings are displayed when setting up a water softener. Settings marked with an
asterisk (*) below are also displayed when setting up a filter.
Setting Screen Display Range Changing the Setting
Units (U.S.
or Metric)
US Inch or
METRIC
Press
or and then to select the units of measure
(in this example, U.S. inch).
Multitank
System
Single,
Progress
Flow,
Alternating,
Unbal Prog
FLow
Multitank systems include two or more tanks in the system (up
to six). They can each be the same size, or one tank can be
smaller (Unbal Prog Flow). Please refer to page 42 for multi-tank
system setup. Press
or and then to specify the
tank configuration.
Tank ID
Master,
Slave1–5
For softeners and filters. This is a multi-tank system setting.
Press
or and then to identify the unit. Refer to
page <?> for info.
Prog Flow
Trip
0–999
For softeners and filters. When a multi-tank (PROGRESS
FLOW) system is selected, press
or and then to
specify this value. Refer to “Setting up a Multi-Tank System” on
page <?>. Set this value on the Master Control only.
Small Tank
Trip
0–999
When Unbal Prog Flow is selected, the smaller tank will have
a lower trip point. Set this value to the trip point of the smaller
tank.
Prerinse
Mode
Off, On
The screen displays the prerinse mode setting, which specifies
the unit drain intervals and durations. Press
or and
then
to change the value from OFF to ON.
Rinse if No
Flow
1–240
The screen displays the rinse interval. If prerinse mode is ON,
the unit will drain if no flow is detected for the duration of this
interval. Press
or and then to change the value.
Rinse For
1–60
The screen displays the rinse duration. If prerinse mode is ON,
specify the number of minutes the unit should rinse to drain
when the RINSE IF NO FLOW duration has passed. Press
or and then to change the setting.
6. The customized setup is complete. The screen displays the advanced setup menu.
Press
to display the home screen.
