Diagnostic Screens 79
Cat. No. 01021161
Setting Screen Display Range Description
SBT
Sensor
BL
OP
Expected Readings on the Sensor/Diagnostic screen when
the SBT probe is installed inside the brine tank. See below for
settings.
Displays BL (= Blocked) Displays OP (= Open)
Salometer Brine at least 1" above the salt plate.
Salt Level Normal Operation. Salt level greater than
8" above the salt plate
Salt level less than 8" above the salt plate
Flow Rate #1 Water level in brine tank is below salt
plate
Water level is brine tank is more than 1"
above salt plate
Flow Rate #2 Water level is brine tank is more than 1"
above salt plate
Water level in brine tank is below salt
plate
Expected Readings from the SBT probe when the probe is not installed in the brine tank.
Normally Probe Inverted
Salometer OP BL
Salt Level OP OP
Flow Rate #1 BL OP
Flow Rate #2 OP BL
SBT
Average
T3
The screen displays the Smart Brine Tank T3 measurement.
In addition to these four sensors, the SBT probe takes a
measurement during each regeneration cycle called T3. This
measurement varies from system to system, but is typically
between 10 and 60 seconds for a system. When the SBT is
turned from UNINSTALLED to INSTALLED on the Accesso-
ries menu, the average value of T3 is erased and the system
will use the next three regeneration cycles to compute a new
T3 average number. During each subsequent regeneration,
the new T3 is compared to the average T3 number. If the new
T3 exceeds the average T3 by more than 50 percent then the
system will display a “Brine Line Blockage—Check Brine Line”
error message. The average T3 value is displayed on the diag-
nostic screen after the SBT sensor screen.
SBT Last
T3
The screen displays the last Smart Brine Tank T3 valve record-
ed by the probe.
Test Wireless, Progressive Flow, and Motor Control
4. From the diagnostics menu, press to select 3)TEST WIRELESS. The
screen displays the wireless test diagnostic.
