Diagnostic Screens 75
Cat. No. 01021161
Diagnostic Screens
There are a large number of diagnostic menu screens to aid in setup and troubleshooting of the Smart Controller. Below
is an overview of the menus.
Advanced Statistics
1. From the HOME screen, press to view the main menu.
2. The screen displays the main menu. Press to select
6)DIAGNOSTICS.
3. The screen displays the diagnostics menu. Press to select 1)ADVANCED
STAT.
4. The screen displays the advanced statistics menu. Press to select 1)FLOW
STATS. The screen displays the first flow statistics information about the softener.
Flow Statistics
Setting Screen Display Range Description
Totalized
Flow
0–9999999
The screen displays the Totalized Flow, the total number of
gallons of soft water since the unit was installed. Press
to
view the next statistic.
Current
Flowrate
0.0–999999
The screen displays the current flow rate of the unit. Press
to view the next statistic.
Flow
Profile
R1–R6
R1–R6
0–9999999
The screen displays the Flow Profile, the amount of time that
the unit spends within different flow ranges. Press
to return
to the Advanced Stats menu.
To Next Page
