R-net Omni2 Technical Manual | Chapter 6 – Bluetooth Set-Up & Operation | 105
SK81935-01
2 PAIRING WITH A BLUETOOTH® DEVICE
The Omni2 must first be put into Discovery Mode via the sequence below.
 Enter Bluetooth® Mode and select the device you wish to pair with.
 Deflect the SID in the forward direction and hold until there is a beep. This will take approximately 10 seconds, then
release.
 Deflect the SID in the reverse direction and hold until there is a beep. This will take approximately 10 seconds, then
release.
A screen such as below will appear – the flashing blue icon confirming the Omni2 is in Discovery Mode.
Depending on which type of device is being paired with – a Windows PC, an Android device or an iDevice – refer to one of the
following three sections.
2.1 PAIRING WITH A WINDOWS PC
If the PC does not have integrated Bluetooth®, then a receiver Dongle must be used and its drivers installed.
Curtiss-Wright recommends use of the following Bluetooth® Dongles:
 Trust BT-2400
 Linksys USBBT100-UK
 Belkin F8T012uk1 Version 1000
Once a Bluetooth® connection is confirmed, the following process should be undertaken on the PC (based on Windows 10):
