There is a further programmable parameter associated with the operation of the User Switch, Switch Medium. This parameter
is only applicable with 3-Axis-Type SIDs, i.e. 3-switch head controls. Refer to the Programming chapter for full details of this
function.
9.2 ACCESSING POWERCHAIR FUNCTIONS
The Omni2 can be programmed to access all the available powerchair functions in two ways – by Menu or by Sequence. The
programmable parameter that sets the access method is User Control.
The Menu method is whereby an activation of the User Switch while in Drive Mode will bring up an on-screen User Menu as
shown below. SID direction commands are then used to navigate the menu and select functions.
The Sequence method is whereby successive activations of the User Switch will sequentially access all the powerchair
functions.
NOTE (HP, IN)
It is not advisable to program the menu options, Speed Adjust or Profile Select, if the Sequence method is being used with
scanning operation. Refer to the Programming chapter for further details.
9.3 ORDER OF USER MENU OR SEQUENCE
Using the programmable parameter, Position 1 to Position 16, it is possible to change the order of the options on the User
Menu. The User Menu can have a maximum of 16 lines and the content of each of the lines is set by these parameters. If the
Sequence method is being employed, then these parameters set the order of the sequence.
A further programmable option for the Menu method of operation is Return To. This parameter sets whether an operation of
the User Switch while in a non-Drive Mode takes the user back to Drive Mode or back to the User Menu.
The function of some of the options in the User Menu is also programmable. Refer to the Position 1 Type to Position 16 Type
section in the Programming chapter for further details.
