138 | R-net Omni2 Technical Manual | Chapter 8 – Diagnostics
3.30 RIGHT SIGNAL 2 OPEN CIRCUIT
This occurs when the Omni2 has detected that the Right signal from the Port 2 D-type connector has become open-circuit.
Refer to the Specifications chapter for connection details.
 Check the operation of the SID and all cables and connectors between the Omni2 and the Port 2 D-type connector.
If the trip is still present after the above checks have been made, then the SID or Omni2 may be defective. Refer to Section 5.
3.31 LEFT SIGNAL 2 OPEN CIRCUIT
This occurs when the Omni2 has detected that the Left signal from the Port 2 D-type connector has become open-circuit.
Refer to the Specifications chapter for connection details.
 Check the operation of the SID and all cables and connectors between the Omni2 and the Port 2 D-type connector.
If the trip is still present after the above checks have been made, then the SID or Omni2 may be defective. Refer to Section 5.
3.32 FORWARD SIGNAL 2 OPEN CIRCUIT
This occurs when the Omni2 has detected that the Forward signal from the Port 2 D-type connector has become open-circuit.
Refer to the Specifications chapter for connection details.
 Check the operation of the SID and all cables and connectors between the Omni2 and the Port 2 D-type connector.
If the trip is still present after the above checks have been made, then the SID or Omni2 may be defective. Refer to Section 5.
3.33 REVERSE SIGNAL 2 OPEN CIRCUIT
This occurs when the Omni2 has detected that the Reverse signal from the Port 2 D-type connector has become open-circuit.
Refer to the Specifications chapter for connection details.
 Check the operation of the SID and all cables and connectors between the Omni2 and the Port 2 D-type connector.
If the trip is still present after the above checks have been made, then the SID or Omni2 may be defective. Refer to Section 5.
3.34 FIFTH SWITCH 2 OPEN CIRCUIT
This occurs when the Omni2 has detected the Fifth Switch from the Port 2 D-type connector has become open-circuit. Refer
to the Specifications chapter for connection details.
 Check the operation of the SID and all cables and connectors between the Omni2 and the Port 2 D-type connector.
If the trip is still present after the above checks have been made, then the SID or Omni2 may be defective. Refer to Section 5.
