CHAPTER 9 – SPECIFICATIONS
1 GENERAL SPECIFICATIONS
Supply Voltage: 24Vdc
Operating Voltage: 16V-35Vdc
Reverse Battery Voltage: 40Vdc
LCD Display: 480 x 680 (Portrait) 3.5” Color
Bluetooth® Range: 10 Meters
SID Supply Voltage: 12Vdc (Programmable On/Off)
USB Charging Port: Type A
Charger Connector: Use only Neutrik NC3MX
Battery Charging Current: 12Arms max.
Moisture Resistance: Electronics to IPX4
Operating Temperature: -25°C to 50°C
Storage Temperature: -40°C to 65°C
EMC tested on sample wheelchair:
Susceptibility: Tested at 30V/m to EN12184 and ANSI/ RESNA requirements
Emissions: To EN55022 Class B
ESD: IEC801 part 2
For complete electrical specifications of the R-net Control System, refer to the R-net Technical Manual SK77981.
2 BLUETOOTH® REGULATORY REQUIREMENTS
This product contains a Class 2 Bluetooth® transmitter device with a range of up to 10 meters.
If the product is used in areas where mobile phones are required to operate in a flight-safe mode, then the Bluetooth®
transmitter should be temporarily disabled as described in the product technical manual.
The Bluetooth® controller must only be used for the intended purpose as explained in the product technical manual. It must
not be use in any safety-critical, life-supporting, or life-sustaining applications.
2.1 RISK ASSESSMENT INFORMATION
2.1.1 RSA 1.1:
The Bluetooth® controller must only be used for the intended purpose as explained in the product technical manual. It must
not be use in any safety-critical, life-supporting, or life-sustaining applications.
