5.1 GENERAL CARE
Avoid knocking the control system, especially the Display Section.
When transporting the powerchair, ensure the control system is well protected.
To prolong the life of the control system, keep exposure to extreme conditions to a minimum.
Always clean your control system if it becomes contaminated with food or drink.
NOTE (OP, HP, IN)
When cleaning the control system, use a damp, non-abrasive cloth and washing-up liquid mixed with water. Do not use
abrasive or spirit-based cleaning agents.
6 INSTALLING THE SID ONTO A POWERCHAIR
WARNING (HP, IN)
The SID should be fitted to the powerchair in accordance with the instructions of both the SID and powerchair
manufacturers. Curtiss-Wright accept no liability for losses of any kind resulting from an incorrect installation of a SID.
Because of the wide variety of SIDs available and the constantly changing specifications, it is not practical to provide a
definitive list of SID classifications in this manual. Instead, the healthcare professional may have to contact the SID
manufacturer, the powerchair manufacturer and/or Curtiss-Wright to determine the exact classification of the chosen type of
SID. Further details on each SID type are given in the following sections.
In addition to the SID for controlling the powerchair functions, the Omni2 has facility for the connection of an optional, user
operated On/Off switch. The function of this switch is identical to the On/Off button on the Omni2’s front panel.
Refer to the Specifications chapter for full electrical specifications of the SIDs and On/Off switch.
6.1 CONNECTION OF SID
For single SID operation, always connect the SID to Port 1.
Port 1 comprises:
A stereo 3.5mm / 1/8” jack for the User Switch.
A 9-way input connector with a TRACE standard pin-out.
