4.5 PINS 7 AND 9 – 12V 100MA
These pins are connected together inside the Omni2 and provide a 12V supply to the joystick. The total combined current
capability is 100mA.
4.6 PIN 8 – JOYSTICK GROUND
A 0V supply for the joystick.
5 DIGITAL SIGNAL LEVELS
5.1 PINS 1, 2, 3 AND 4 – DIRECTION
Low signal < 0.7V.
High signal > 1.4V.
Impedance: 132K to 3V.
5.2 PIN 6 – FIFTH SWITCH
Low signal < 0.7V.
High signal > 1.4V.
Impedance: 100K to 5V.
5.3 PIN 5 – DETECT
This pin should be linked to 0V inside the input device. This link allows the Omni2 to detect if the input device is connected. If
the link is not fitted, the Omni2 should be configured to ignore the absence of the link.
5.4 PINS 7 AND 9 – 12V 100MA
These pins are connected together inside the Omni2 and provide a 12V supply to the input device. The total combined current
capability is 100mA.
5.5 PIN 8 – 0V
A 0V supply for the input device.
