4.24 OMNI SID INFORMATION
WARNING (HP, IN)
The information in the remainder of this section can be used to design Specialty Input Devices compatible with the Omni2.
The input device manufacturer must ensure that the SID design is safe under all conditions, in particular, single component
failures must be detected and the input device put into a safe condition. Curtiss-Wright accept no responsibility for losses of
any kind resulting from an unsuitable SID design.
4.25 9-WAY D-TYPE PIN-OUT
WARNING (HP, IN)
The mating 9-way D-type connector (socket) should always be fitted with gold contacts and a suitable backshell with locking
screws. These locking screws should be used to mechanically hold the connector firmly in place.
