130 | R-net Omni2 Technical Manual | Chapter 8 – Diagnostics
3 DIAGNOSTIC TEXT DEFINITIONS
Once the Omni2 trip text has been established, use the following definitions to ascertain the possible cause and required
corrective procedure. If the trip text does not appear in the following table, refer to the R-net Technical Manual SK77981 for
further details.
Trip Text
Referral Point
Center Joystick
Refer to section 3.1
Jstick Cal Error
Refer to section 3.2
Latched Timeout
Refer to section 3.3
DIME Error
Refer to section 3.4
Memory Error
Refer to section 3.5
Bad Cable
Refer to section 3.6
Bad Settings
Refer to section 3.7
Module Error
Refer to section 3.8
System Error
Refer to section 3.9
SID Detached
Refer to section 3.10
Switch Detached
Refer to section 3.11
Over Pressure
Refer to section 3.12
Gone to Sleep
Refer to section 3.13
Charging
Refer to section 3.14
JS Static Timeout
Refer to section 3.15
User Switch 1 Open Circuit
Refer to section 3.16
User Switch 1 Short Circuit
Refer to section 3.17
User Switch 2 Open Circuit
Refer to section 3.18
User Switch 2 Short Circuit
Refer to section 3.19
Right Signal 1 Open Circuit
Refer to section 3.20
Left Signal 1 Open Circuit
Refer to section 3.21
Forward Signal 1 Open Circuit
Refer to section 3.22
Reverse Signal 1 Open Circuit
Refer to section 3.23
Fifth Switch 1 Open Circuit
Refer to section 3.24
Right Signal 1 Short Circuit
Refer to section 3.25
Left Signal 1 Short Circuit
Refer to section 3.26
Forward Signal 1 Short Circuit
Refer to section 3.27
Reverse Signal 1 Short Circuit
Refer to section 3.28
Fifth Switch 1 Short Circuit
Refer to section 3.29
Right Signal 2 Open Circuit
Refer to section 3.30
Left Signal 2 Open Circuit
Refer to section 3.31
Forward Signal 2 Open Circuit
Refer to section 3.32
Reverse Signal 2 Open Circuit
Refer to section 3.33
Fifth Switch 2 Open Circuit
Refer to section 3.34
Right Signal 2 Short Circuit
Refer to section 3.35
Left Signal 2 Short Circuit
Refer to section 3.36
Forward Signal 2 Short Circuit
Refer to section 3.37
Reverse Signal 2 Short Circuit
Refer to section 3.38
Fifth Switch 2 Short Circuit
Refer to section 3.39
