A cross denotes an unsuccessful learn operation, please retry.
NOTE (HP, IN)
The first time an IR Code has been learnt, it is necessary to cycle the power to the Omni2. If other IR Codes are already
learnt, then this is not necessary.
4.1 LEARNING AN IR CODE - SEQUENCE
Multiple IR Codes can be learnt against one Command in the Omni2 IR Set-Up Menu. This enables multiple IR Codes to be
transmitted through one Command in the Omni2 when in IR mode.
Examples:
1. The On/Off function for multiple appliances (the TV and the DVD for example) can be learnt against one entry in the
Omni2 menu. The Omni2 will then transmit the Codes for the learnt Command in one burst. In this case turning the
TV and the DVD recorder on or off, effectively simultaneously.
2. Previously selecting a TV channel required the user to select the individual channel’s digits from a list. This could be
quite cumbersome when trying to select a TV channel with multiple digits e.g. Channel 143. Now the individual
Codes for “1”, ”4” and “3” can be learned against one Command in the Omni2 IR Set Up Menu. When this Command
is selected in IR Mode, the IR Codes are transmitted effectively simultaneously.
To create a Sequence:
Select the Command to use as the Sequence initiator. In this example, TV > On/Off.
Select Learn Code, by using the Right button while the Command is highlighted.
Point the TV remote control at the Omni2’s Receiver and press the On/Off button twice.
After each successful learn operation a check momentarily appears on the screen, select Learn Code again.
Point the DVD remote control at the Omni2’s Receiver and press the On/Off button twice.
After each successful learn operation a check momentarily appears on the screen, select Learn Code again.
This time, the On/Off Command will have a Tick and three Dots beside it, showing a Learnt Sequence. As displayed below.
