User's Manual
178
Parameters Description
IP Type Select IPv4 or IPv6.
Use Dynamic IP
Address
When there is a DHCP server on the network, you can enable DHCP. The
system allocates a dynamic IP address to the Device. There is no need to
set IP address manually.
Use Static IP Address
Set a static IP address for the Device. You need to enter a static IP
address, subnet mask and gateway. It is to
Test Test whether the IP address is valid.
MTU
Set NIC MTU value. The default setup is 1500 bytes.
We recommend you check the MTU value of the gateway first and then
set the MTU value of the Device equal to or smaller than the gateway
value, which helps to reduce the packets slightly and enhance network
transmission efficiency.
Please be advised that changing MTU value might result in NIC restart,
network offline and affect current running operation.
6) Click
OK
.
Step 5 Click
Apply
.
The system pops up a confirmation box.
Step 6 Click
OK
.
The configuration of binding NICs takes effect after the Device restarts.
8.2.1.2.2 Cancelling Binding NIC
Cancel port aggregation so that the NICs are no longer bonded and work as independent NICs.
Procedure
Step 1 Log in to the PC client.
Step 2 Click on the upper-right corner and then click
Network
.
You can also click
Network
from the configuration list on the home page.
Step 3 Select a bonded NIC.
Step 4 Click
Unbind
.
Figure 8-15 Unbind
