User's Manual
255
8.4.1.6 Snapshot
Set the snapshot linkage action for alarms, so that once an alarm happens, it will trigger a snapshot
of the alarm.
Click
Actions, and then select Snapshot.
Figure 8-42 Snapshot action
8.4.1.7 Local Alarm Out
Set local alarm output. System can trigger the corresponding alarm event when an alarm occurs.
Make sure that the Device is connected with alarm output device.
Step 1 Click Actions and select Local Alarm Out.
Figure 8-43 Local alarm out
Step 2 Select alarm output port.
You can select multiple alarm output ports.
Step 3 Set delay time.
Set a delay time. After alarm event is ended, alarm will end after the delay time. You can
configure from 0 seconds through 300 seconds, and the default value is 10 seconds.
8.4.1.8 Remote Device Alarm Output
Set remote device alarm output. The system can link the corresponding alarm output device to
output alarm when an alarm occurs.
Make sure that the remote device has been added, and the remote device is connected with alarm
output device. See "5.4.2 Adding Remote Device" for detailed information.
Step 1 Click Actions and select Remote Device Alarm Output.
Figure 8-44 Remote device alarm output settings
Step 2 Select a remote device and alarm output port.
You can select multiple alarm output ports.
Step 3 (Optional) Repeat Step 1–Step 2, and link multiple remote alarm output devices.
