User's Manual
185
Please be advised that services and ports of the Device will be mapped to the public network after
UPnP is enabled.
Procedure
Step 1 Log in to the PC client.
Step 2 Click on the upper-right corner and then click
Network
.
You can also click
Network
from the configuration list on the home page.
Step 3 Select
NETWORK
>
Network Apps
>
UPnP
.
Figure 8-21 UPnP
Step 4 Set parameters.
Table 8-11 UPnP parameters
Parameter Description
Port Mapping Click to enable port mapping.
Status The status of port mapping.
LAN IP
The LAN IP address of the router.
The IP address is automatically obtained after the mapping succeeds.
WAN IP
The WAN IP address of router.
The IP address is automatically obtained after the mapping succeeds.
To Next Page
