User's Manual
238
Figure 8-23 Edit load balance
5) Set parameters.
Table 8-8 TCP/IP parameters description
Speed Maximum network transmission speed of current NIC.
IP Type Select IPv4 or IPv6.
Use Dynamic IP
Address
When there is a DHCP server on the network, check the box to use
dynamic IP address. System can allocate a dynamic IP address to the
device. There is no need to set IP address manually.
Use Static IP Address
Check the box to use static IP address. Set static IP address, subnet mask
and gateway. It is to set a static IP address for the device.
Test Test whether the IP address is valid.
MTU
Set NIC MTU value. The default setup is 1500 Byte.
We recommend you to check the MTU value of the gateway first and
then set the device MTU value equal to or smaller than the gateway
value. It is to reduce the packets slightly and enhance network
transmission efficiency.
Please be advised that changing MTU value might result in NIC reboot,
network offline and affect current running operation.
6) Click OK.
Go back to
TCP/IP page.
Step 3 Click Save.
System pops up a confirmation box.
Step 4 Click OK.
The binding card information becomes activated after reboot operation.
