User's Manual
256
Figure 8-87 Add a main device
2) Set parameters.
Table 8-37 Parameters description
Parameter Description
Device Name Enter a name for the main device.
IP Address Enter the IP address of the main device.
Port Enter the port number. It is 37777 by default.
Username
Enter the login username and password of the Device.
Password
Enable Cluster
Select the checkbox to enable cluster, and then enter the cluster IP
address, subnet mask and gateway.
Cluster IP is a virtual IP that is used to access and manage the main
devices and sub devices in the cluster. After logging in with the
virtual IP, when the main device fails and the system is switched to
the sub device, you can still view live video.
3) Click
OK
.
Step 6 Add a sub device.
1) Click
Add
under
Sub Device
.
