User's Manual
318
Table 8-41 Display parameters description
Resolution
Set display resolution. Different displays support different
resolutions. See your actual interface for detailed information.
Refresh rate Set refresh rate of the display.
Step 5 Click Save.
8.8.4 Schedule
Set schedule. When you are configuring alarm, record arm/disarm period, system can call the
schedule directly. System only triggers the corresponding operations during the specified schedule.
Default schedule has been created by default. Default schedule is Always Effective, and cannot be
modified or deleted.
Step 1 Click , or click on the configuration page, and then select
SYSTEM > Schedule >
Schedule .
Figure 8-119 Schedule
Step 2 Add schedule.
1) Click .
2) Set schedule name.
3) Click
OK to save the configuration.
Step 3 Set valid time period. It includes Always Effective and Customize.
Step 4 Set validity period of schedule.
●
The step is for customized mode only.
●
Each calendar supports maximum 50 validity periods.
●
The blue area on the time bar means the validity period.
On the time bar, you can:
