User's Manual
12
Table 2-6 IVSS7016 rear panel description
1 Power input port Inputs 100–240 VAC power.
2 AI module indicator light
Displays AI module status.
●
The yellow light flashes: AI module is running
properly.
●
The yellow light is on: AI module is
malfunctioning.
This function is valid if there is AI module.
3 RESET button Reserved.
4 HDMI port
High definition audio and video signal output port.
The port outputs the uncompressed high definition
video and multi-channel audio data to the
connected display with HDMI port. The three HDMI
ports are different source output.
5 VGA port
VGA video output port. It outputs analog video
signal. The VGA port and HDMI 1 port are same
source output.
6 RS-232 port
RS-232 COM debug. It is used for general COM
debug, setting IP address, and transmitting
transparent COM data.
7
AUDIO IN Audio input port
AUDIO OUT Audio output port
8 eSATA port
SATA peripheral port. Connects to SATA port or
eSATA device.
9 USB port
Connects to external devices such as USB storage
device, keyboard and mouse.
10 SAS port
SAS extension port. It can connect to the SAS
extension controller.
11 Network port
10/100/1000 Mbps self-adaptive Ethernet port.
Connects to the network cable.
12 Alarm Input
16 groups (1–16) alarm input ports. They are
corresponding to ALARM 1–ALARM 16. The alarm
becomes valid in low level.
●
A and B: Control the A/B cable of the RS–485
device. It is used to connect to the PTZ camera.
Please connect 120Ω between A/B cables if
there are too many PTZ decoders.
●
: GND end.
