116 5.9 Wiring Example for intelligent Touch Controller (DCS601C51)
intelligent Touch Controller
5.9.6 Other Air Conditioner+Di,Dio Units
DCS601C51 (Back side)
Forced OFF contact input
[Field Supply]
8 ports: use for connection with the
equipment of the other companies
4 ports: use for connection with the
equipment of the other companies
For UAT(Y)-K(A),FD-K
For SkyAir Series
Up to 64 groups can be connected
Remark
Model/SpecArrangementEquipment
DEC102A51DAIKINDio
DEC101A51
§ 9.3
§ 9.2
Reference
§ 9.5
§ 9.4
DAIKINDi
DTA107A55DAIKINCentral control adaptor kit*
DTA102A52DAIKINInterface adaptor for SkyAir-series*
DCS601C51DAIKINIntelligent Touch Controller
DIII-NET
*: Adaptors required to connect products other than those of the VRV System to the high-speed DIII-NET
communication system adopted for the VRV System.
* To use any of the above optional controllers, an appropriate adaptor must be installed on the product
unit to be controlled.
Switch
Power Supply
1φ 220-240V 50Hz
Power Supply
DIII
Contact Signal
up to 64
groups of
A/Cs and equipment
Dio
Control of
Lighting
Ventilation
etc…
DEC
102A51
F1 F2
Di
Monitoring
of access
control
DEC
101A51
F1 F2
Outdoor Unit
L3 NL2L1
A B C F1
F2
F1
F2 Q1Q2
Outdoor Unit
L3 NL2L1
A B C F1
F2
F1
F2 Q1Q2
Outdoor Unit
L3 NL2L1
A B C F1 F2 F1 F2 Q1Q2
Outdoor Unit
L3 NL2L1
A B C F1 F2 F1 F2
Q1Q2
R/C
F1 F2 P1 P2
Indoor Unit
R/C
F1 F2 P1
P2
Indoor Unit
F1
F2 P1 P2
Indoor Unit
Outdoor Unit
L3 N
L2L1
A B C F1
F2
F1
F2 Q1Q2
R/C
R/C
R/C
Adaptor kit
(DTA107A55)
[DAIKIN OP]
Interface adaptor for SkyAir
series (built-in indoor unit)
(DTA102A52)
[DAIKIN OP]
Outdoor-air
processing unit
can be connected.
R/C R/C
R/C
R/C
Remote Control
