214 1.11 Backup Systems for Troubles
Interface for Use in BACnet
®
1.11 Backup Systems for Troubles
1.11.1 Failure in the System and its Backup Operation
Note :
1. ( ) indicates that backup operation of all or part of functions within the scope of influence by equipment failure is
possible.
“Corresponding group” is a group of air-conditioner controlled by local remote controller, where the failure is occurred.
“Corresponding system” is a group of air-conditioner controlled by Interface for use in BACnet
®
, where the failure is
occurred.
2. The chance that all local remote controllers and Interface for use in BACnet
®
becomes out of order is almost
negligible, so that the case is not included in the above.
Place of failure Scope of
influence by
failure (Note 1)
Operation when failure occurs.
(description of backup)
Central
monitoring
panel
Interface
for use in
BACnet
®
Central
remote
controller
Local
remote
controller
Air-
conditioning
unit
1
{{{{
✕
Corresponding
air-conditioning
unit
Corresponding air-conditioning unit is shut-down. The
details of failure is converted into code and transferred
to the central monitoring panel by the status change
notification system. The contents of failure is
displayed on local remote controller or central remote
controller.
2
{{{
✕
{
(Corresponding
group)
Operation, setting and monitoring is not possible by
local remote controller. Disconnect the power of the
indoor unit once and turn the power on again, so that
the backup operation is carried out by central remote
controller.
3
{{
✕
{{
(Corresponding
system)
Operation, setting and monitoring is not possible by
the central remote controller. The backup operation is
carried out by central monitoring panel or local remote
controller.
4
{{{{ {
(Corresponding
system)
Operation, setting and monitoring is not possible by
central monitoring panel. Central remote controller
and local remote controller can backup the operation.
5
{
✕
{{ {
(Corresponding
system)
Operation, setting and monitoring is not possible by
central monitoring panel. Central remote controller
and local remote controller can backup the operation.
6
✕
{{{ {
(Entire system) Operation, setting and monitoring is not possible by
central monitoring panel. Central remote controller
and local remote controller can backup the operation.
7
{{
✕✕
{
(Corresponding
system)
Operation, setting and monitoring is not possible by
central remote controller and local remote controller.
Disconnect the power of the indoor unit once and turn
the power on again, so that the backup operation is
carried out by central remote controller.
8
{{
✕
{{
(Corresponding
system)
Operation, setting and monitoring is not possible by
central monitoring panel and the central remote
controller. The backup operation is carried out by local
remote controller.
9 Communication line between indoor unit and local
remote controller is shorted or disconnected.
(Corresponding
group)
Operation, setting and monitoring is not possible by
local remote controller. Disconnect the power of the
indoor unit once and turn the power on again, so that
the backup operation is carried out by central remote
controller.
10 Communication line between Interface for use in
BACnet
®
and indoor unit is shorted or disconnected.
(Corresponding
system)
Operation, setting and monitoring is not possible by
central monitoring panel and the central remote
controller. The backup operation is carried out by local
remote controller.
11 Communication line between Interface for use in
BACnet
®
is shorted or disconnected.
(Entire system) Operation, setting and monitoring is not possible by
central monitoring panel. Central remote controller
and local remote controller can backup the operation.
