1.6 Selection of Control Mode No. 139
Control Devices
 Since the timer number will be set to after-press priority, the timer number in the last screen set will be valid
for the connected units.
Example 1
Setting timer number 1 for unit 1-00 to "1" and timer number 2 to "2" in the individual screen and then setting timer
number 1 to "3" and timer number 2 to "4" in the batch screen causes the timer numbers for all units to be set, so timer
number 1 for unit 1-00 will be "3" and timer number 2 will be "4".
Example 2
To prevent leaving units on, timer number 1 is set to "5" in the batch screen.
Setting timer number 1 in zone number 1 to " " in the zone screen after that will change the timer number for zone
number 1, so the setting to prevent leaving the units on will be lost for zone number 1 only.
If a timer number is set incorrectly by accident, redo the setting in the desired screen.
 What happens when the timer number on time and off time are set to the same time
When the on time and off time are set to the same time for the same timer number, operation does not change.
When the on time and off time are set to the same time for different timer numbers, the off time is given priority.
When using timer operation, make sure the times do not overlap when setting the program of the schedule timer.
3P124623-3A
1.6 Selection of Control Mode No.
Control Mode Setting by Remote Controller (Field Setting)
The control mode defines the function of local remote controllers to handle various types of control and applications.
Function can be defined by conditions and combinations of local remote control operations such as ON/OFF etc. (See
table below.)
Operation can always carried out from the central remote controller.(Except when connected to the central monitoring
panel.)
 Description of Control Mode
The following 5 operation control modes and 20 modes combined with temperature and operation mode setting by the
remote controller are set and display by the control mode of 0 through 19.
Remote Control Rejection
For when you want to turn on/off using central remote controller only.
(On/off cannot be carried out by remote controller.)
Remote controller Off Only Accepted
For when you want to turn on only by the central remote controller, and turn off only by local remote controller.
Central Priority
For when you want to turn on only by the central remote controller, and during the set time, turn on/off freely by local
remote controller.
Individual Priority (Last Command Priority)
For when you want to turn on/off by both central remote controller and local remote controller.
Remote Controller Permission Timer
For when you want to turn on/off by local remote controller during set time, but you do not want to start operation from the
central remote controller at the programmed time of system start.
Note:
The control mode consists of numbers 0 through 19, but only 0 through 9 are usually set.
