Daikin D-BACS - Intelligent Touch Controller (DCS601 C51); Intelligent Touch Controller (DCS601 C51) with the Software for P.P.D. Application (DCS002 C51) Including PCMCIA Card and with the Software for WEB Usage (DCS004 A51); WEB Usage (DCS004 A51)

270
Power Proportional Distribution (P.P.D.)
3. intelligent Touch Controller (DCS601C51) with the Software for P.P.D. Application (DCS002C51) Including PCMCIA Card and with the Software for WEB Usage (DCS004A51)
DCS601C51 (Back side)
kWh-meters
[Field Supply]
•1 Pulse to 1 kW·h or 10 kW·h pulse
width must be within 40-400 m/sec.
•Output relay must be electronic type
only.
• No voltage output
•Pulse transmitterField SupplykW·h meter
Activation number card included
PCMCIA card is included.
DCS002C51DAIKIN
Option for
Intelligent Touch
Controller (P.P.D)
Activation number card included
DCS004A51DAIKIN
Option for
Intelligent Touch
Controller (Web)
•Performance :
Pentium III:
800MHz,Memory:256MB,HDD:4G
•Network:100Base/T Ethernet
•Operation:
Keyboard/Mouse,Sound and Speaker
•Software:
Windows XP(Professional SP2 or later)
Windows 2000(Professional SP4 or later)
•CRT:SVGA(800x600,1024x768,1280x1024 )
Field SupplyPC
Supporting 100Base/TField SupplyHUB
Up to 64 groups can be connected
DCS601C51DAIKIN
Intelligent Touch
Controller
Remark
Model/SpecArrangementEquipment
DIII-NET
Hub
[Field Supply]
.CSV
Power
Supply
3φ 4W 380-415V
Refer to field wiring on previous page
about power supply wiring.
Note)
50Hz
The power consumption of the outdoor unit can
be proportionally calculated for each indoor unit
using the intelligent touch controller and the
Power Proportional Distribution software. The
calculated results are recorded in the intelligent
touch controller for last 13 months. The
recorded, proportionally calculated results can
be taken outfrom a remote PC through the
LAN.
up to 64 units of
A/Cs and equipment
R/C
F1 F2 P1 P2
Indoor Unit
F1 F2 P1 P2
Indoor Unit
Outdoor Unit
L3 NL2L1
A B
C F1 F2 F1 F2 Q1Q2
Outdoor Unit
L3 NL2L1
A B
C F1 F2 F1 F2 Q1Q2
Outdoor Unit
L3 NL2L1
A
B C F1 F2 F1 F2 Q1Q2
Outdoor Unit
L3 NL2L1
A B C F1 F2 F1 F2 Q1Q2
Outdoor Unit
L3
N
L2L1
A B C F1 F2
F1 F2 Q1Q2
R/C
F1 F2 P1 P2
Indoor Unit
R/C
R/C
CSV output of P.P.D. PCMCIA
[DAIKIN option attached P.P.D.]
DAIKIN
When taking out Power Proportional Distribution data
via Web,
it is possible without a PCMCIA card.
Switch
Power Supply
1φ 220-240V 50Hz
Power Supply
DIII
Contact Signal
Remote Control
