204 1.7 BACnet Object List
Interface for Use in BACnet
®
1.7 BACnet Object List
Central control (lower central control disable) and forced system stop are only available for 000, 064, 128, and 192.
(Note 1) The room temperature is measured with the suction air. Since the indoor unit fan stops when the thermostat is disabled or the
air conditioner is stopped, or in a special operation such as defrosting, temperature measurement may be affected by the heat
exchanger, and may detect and transmit a different temperature from the actual room temperature. For this reason, this value
should be considered as a reference for the room temperature.
If the building management system manufacturer uses this value for system control (e.g., switching the air-conditioning mode or
preset temperature), the manufacturer must take on the whole responsibility.
(Note 2) The air conditioner saves the settings for the temperature, start / stop status, air-conditioning mode, air direction, and air flow
rate in the nonvolatile memory each time they are changed, so that the settings will not be lost when a power cut occurs. This
nonvolatile memory has a write count limit and may cause a failure if it is written exceeding the limit count.
Therefore when the temperature, start / stop status, air-conditioning mode, air direction, and air flow rate of each indoor unit are
automatically controlled from the central monitoring panel, be sure that the number of changes for each setting should not
exceed 7,000 times per year
.
Member
number
Standard name Object name
(XXX represents the air
conditioner number.)
Object
type
Unit
Inactive Active
Text-1 Text-2 Text-3 Text-4
1 Start / stop (setting) (Note 2) StartStopCommand_XXX BO Stop Operation
2 Start / stop (status) StartStopStatus_XXX BI Stop Operation
3 Alarm Alarm_XXX BI Normal
Malfunction
4 Malfunction code MalfunctionCode_XXX MI Normal Manufacturer specific
5 Air-conditioning mode (setting)
(Note 2)
AirConModeCommand_XXX MO Cooling Heating Fan Auto
6 Air-conditioning mode (status) AirConModeStatus_XXX MI Cooling Heating Fan
7 Air flow rate level (setting)
(Note 2)
AirFlowRateCommand_XXX MO Low High
8 Air flow rate level (status) AirFlowRateStatus_XXX MI Low High
9 Measured room temperature
(Note 1)
RoomTemp_XXX AI °C
10 Set room temperature (Note 2) TempAdjust_XXX AV °C
11 Filter sign signal FilterSign_XXX BI No Yes
12 Filter sign signal reset FilterSignReset_XXX BV Reset
13 Remote controller enable /
disable (start / stop)
RemoteControlStart_XXX BV Enabled Disabled
14 Remote controller enable /
disable (air-conditioning mode)
RemoteControlAirConModeSet
_XXX
BV Enabled Disabled
15 Blank
16 Remote controller enable /
disable (set temperature)
RemoteControlTempAdjust_
XXX
BV Enabled Disabled
(*)17 Central control
(lower central control disable)
CL_Rejection_XXX BV Enabled Disabled
18 Blank
19 Accumulated power ElecTotalPower_XXX
Accumulator
kWh
20 Communication status CommunicationStatus_XXX BI
Normal
communication
Communication
error
(*)21 Forced system stop SystemForcedOff_XXX BV
Clearance
Forced stop
22 Air direction (setting) (Note 2) AirDirectionCommand_XXX AV
23 Air direction (status) AirDirectionStatus_XXX AI
24 Forced thermostat disable
(setting)
ForcedThermoOFFCommand_
XXX
BO
Clearance
Set
25 Forced thermostat disable
(status)
ForcedThermoOFFStatus_
XXX
BI
Clearance
Set
26 Energy saving (setting) EnergyEfficiencyCommand_
XXX
BO
Clearance
Set
27 Energy saving (status) EnergyEfficiencyStatus_XXX BI
Clearance
Set
28 Thermostat status ThermoStatus_XXX BI OFF ON
29 Compressor status CompressorStatus_XXX BI Stop Operation
30 Indoor fan status IndoorFanStatus_XXX BI Stop Operation
31 Heater operation status HeaterStatus_XXX BI Stop Operation
