4.2 Applicable Models 229
Interface for use in LONWORKS
®
4.2 Applicable Models
∗
1 Engineered & Industrial Systems Div. prohibits a connection between the fan unit and intelligent Touch Controllers (and other central
operation equipment).
∗
2For
∆
parts, consult with Engineered & Industrial Systems Div.
Function Names VRV Sky Air HRV
Outdoor Air
Processing Unit
FXYM-KF, MF
Wiring Adaptor for
Other Air
Conditioner
Central
Control
Adaptor Kit
Fan Coil
Controller ∗15
Fan
Unit
∗14
∗15
Controlling Items
ON/OFF Command
{{{ { { { { {
Operation Mode Setting
{{ × { × {{×
Temperature Setting
{{ ×
× (Not settable by
remote controller)
× {{×
Airflow Rate Setting
{{ ×× × ×
∆ (Only Quick/
Soft)
×
Filter Sign Reset
{{{ { ××{ ×
Forced Thermostat OFF Setting
{{ × { ××××
Remote ON/OFF Control Rejection
{{{ { × {{{
Remote Operation Mode Control
Rejection
{{ × { × {{×
Remote Temperature Setting Control
Rejection
{{ × { × {{×
System Forced OFF Setting
{{{ { { { { {
Sub Group Address Control Rejection
Setting
∗This is a controlling item for subsidiary central operation equipment.
Monitoring Items
ON/OFF Status Report
{{{ { { { { {
Operation Mode Status Report
{{ × { × {{×
Temperature Setting Report
{{ ×× × {{×
Room Temperature Report
{{ ×
{ (Temperature at
the blow-off outlet)
× {
∆ (Only
thermostat for
sucking into
body)
×
Airflow Rate Setting Report
{{ × × (First speed fixed) × ×
∆ (Only Low/
High)
{
Filter Sign Report
{{{ { ××{ ×
Error Status Report
{{{ { { { { ×
Error Code Report
{{{ { × {{{
Thermostat Status Report
{{ × { ××××
Forced Thermostat OFF Setting Status
Report
{{ × { ××××
Remote ON/OFF Operation Rejection
Report
{{{ { × {{{
Remote Control Operation Mode
Setting Rejection Report
{{ × { × {{×
Remote Control Temperature Setting
Operation Rejection Report
{{ × { × {{×
System Forced OFF Setting Report
{{{ { { { { {
Sub Group Address Control Operation
Rejection Setting Report
∗This is a sub group address controlled central operation equipment.
A/C Communication Status Report
{{{ { { { { {
