Daikin D-BACS - Specification and Dimension; Part Names and Functions

2.3 Specification and Dimension 151
Control Devices
2. One indoor unit controlled by one or two remote controllers
3. A maximum of 16 indoor units controlled in groups by one or two remote controllers
C: 1P162827
2.3 Specification and Dimension
 DCS301BA61
2.4 Part names and Functions
One remote
controller
Two remote
controllers
or
Remote
controller
Max.
16 units
Max. 16
indoor units
Two remote
controllers
or
3D050339
ALL I
D1
10
ALL
HOST
02
09
12 13 14
UNIFIED
ON/OFF CONTROLLER
T1
06
T2
2 - 5 × 7 round end slit
D2
05
15
Optional switch box
04
00
08
0301
11
07
F1F2
46
90
71.0
120
83.5
52.5
16
120
DCS301B51 · 61
Unit (mm)
GROUP NO.
ROOM NAME INDICATION
PLATE
Refer to the “2. PUTTING
ROOM NAME INDICATION
STICKER”
UNIFIED OPERATION/STOP
BUTTON
Starts/stops all indoor units.
OPERATION LAMP
Turns on during operation
of each group and flashes
during malfunction stop.
“UNDER HOST COMPUTER
INTEGRATED
CONTROL”LAMP
When this lamp turns on,no
other operations are possible.
INDIVIDUAL
OPERATION/STOP
BUTTON
Starts/stops each
indoor unit group
individually.
