3.8 Wiring Example 193
intelligent Manager
3.8 Wiring Example
3.8.1 intelligent Manager III (IM-256; DAM602B51)
Outdoor Unit
L3 NL2L1
A B C F1F2F1F2Q1Q2
LAN
(Ethernet)
PC,Monitor,Sub PC ,
Hub [Field Supply]
Outdoor Unit
L3 NL2L1
A B C F1F2F1F2Q1Q2
Outdoor Unit
L3 NL2L1
A B C F1F2F1F2Q1Q2
Outdoor Unit
L3 NL2L1
A B C F1 F2 F1 F2 Q1Q2
Outdoor Unit
L3 NL2L1
A
B C F1 F2 F1 F2 Q1 Q2
Outdoor Unit
L3 NL2L1
A B C F1F2F1F2Q1Q2
F1 F2 P1 P2
Indoor Unit
R/C
up to 64×2 groups of
A/Cs and equipment
256 groups
Connectable
The UPS is required for transmitting the interruption signal for the UPS
above to the intelligent manager III body.
APC AP9610Field Supply
The UPS supplies power to the intelligent manager III body, PC and hub.
APC SU700 or SU1000 SeriesField Supply
UPS
•Performance :
Pentium III:800MHz,Memory:256MB,HDD:4G
•Network:100Base/T Ethernet
•Operation:Keyboard/Mouse,Sound and Speaker
•Software:
Windows XP(Professional SP2 or later)
Windows 2000(Professional SP4 or later)
•CRT:SVGA(800x600,1024x768,1280x1024 )
Field SupplyPC
The hub is required for connecting the intelligent manager III body and a PC.
It is connected to the Line port.
100Base/TField SupplyHUB
DIII Port: with 4 ports
DAM602B51DAIKIN
intelligent
Manager III
RemarkModel/SpecArrangementEquipment
Adaptor kit
(DTA107A55)
[DAIKIN OP ]
Interface adaptor for SkyAir
series (built-in indoor unit)
(DTA102A52)
[DAIKIN OP ]
Out door-air
processing unit
can be connected.
R/C R/C
R/C
R/C
R/C
PC
Sub
PC
UPS
[Field Supply]
R/C
F1 F2 P1 P2
Indoor Unit
up to 64×2 groups of
A/Cs and equipment
F1 F2 P1 P2
Indoor Unit
Power Supply
DIII
Contact Signal
[Power Supply]
Adaptor kit
(DTA107A55)
[DAIKIN OP ]
Interface adaptor for SkyAir
series (built-in indoor unit)
(DTA102A52)
[DAIKIN OP ]
Out door-air
processing unit
can be connected.
R/C R/C
R/C
R/C
Dio
Control of
Lighting
Ventilation
etc…
DEC
102A51
F1 F2
Di
Monitoring
of access
control
DEC
101A51
F1 F2
For UAT(Y)-K(A),FD-K
For SkyAir Series
4 ports: use for connection with the equipment of the other companies DEC102A51
DAIKINDio
8 ports: use for connection with the equipment of the other companies DEC101A51
DAIKINDi
Use for measuring ambient temperature. DAM101A51
DAIKINAi
DTA107A55
DAIKIN
Central control adaptor kit*
DTA102A52
DAIKIN
Interface adaptor for SkyAir-series*
Remark Model/Spec
ArrangementEquipment
R/C
F1 F2
Ai
Monitoring of
temp.,Humidity
*: Adaptors required to connect products other than those of the VRV System to the high-speed DIII-NET communication system
adopted for the VRV System.
* To use any of the above optional controllers, an appropriate adaptor must be installed on the product unit to be controlled.
1φ 220-240V 50Hz
R/C
Remote Control
