117
intelligent Touch Controller
6. Web function
Outline of the Web function system
By using the separately sold Web function software with the intelligent Touch Controller, air conditioners connected to the
intelligent Touch Controller may be monitored and controlled by a general purpose computer connected to the intelligent
Touch Controller through the network.
Usage examples are described below.
The Administrator may register (control) air conditioners which can be operated by each general user.
In the following example shown in Fig. 1, the users User 1, User 2, and User 3 are registered as users who may only
monitor and control the nearest air conditioner.
Also, as in the case of user 64, overlapping registering of an air conditioner which can be operated by another user is
possible.
Note : This function may be used by using the separately sold item DCS004A51.
Fig. 1 User setting image Figure
User 1
User 2
User 3
User 64
User 1
User 3
User 2 · 64
Administrator
LAN
Equipment communication
1-00 1-01 1-02
1-03 1-04 1-05
1-06 1-07 1-08
The maximum number of users that
can be registered is 65, including
Administrator = 1,
General users = 64
User 1:
User 2:
User 3:
User 64
:
1-00 1-01 1-02
1-03 1-04 1-05
1-06 1-07 1-08
1-01 1-04 1-07
Registration information
of general users
