3.2 Main Specifications and Functions of the Equipment 13
Outline of D-BACS System
Outline of System
Individual Control (Controls Indoor Units Individually.)
KRP1B56, 57, 59, 61, KRP1C3,
KRP2A61,62 and KRP4A51,52,53
can be built-in together into the
indoor units
Combined use of wiring adaptor for
Electrical Appendices (1) and (2) is not
available.
Group Unified Control (Controls group controlled indoor units all at once and simultaneously.)
Zone Unified Control (Unified, simultaneous control of up to 64 groups of group controlled indoor units
consisting of up to 16 units each.)
Intelligent touch controller
(Proportional division software is used)
Wh1
Power supply
Single phase 100-240V
Electric
meter
Electric
meter
Electric
meter
Outdoor unit
Outdoor unit Outdoor unit Outdoor unit
Outdoor unit
Power supply
Power supply
Power supply
Outdoor unit
Indoor unit Indoor unit Indoor unit
Wh2 Wh3
To Next Page
