304 1.5 Dio Unit (DEC102A51)
Adaptor
2. Specifications
Output specs: Voltage free “a” contact
Input specs: Voltage free “a” contact
Micro current load contact input (DC12V, 1 mA or less)
Wiring length: 150 m
Dio board
Input contacts
8 points.
4 pairs based on a pair of On/Off input and abnormality input
* Contact information(On/Off, Abnormality ) is transmitted to
intelligent Manager III through DIII-Net communication.
Output contacts
4 points.
In case of normally output, 4 units are controllable.
In case of instantaneous output, 2 units are controllable.
* From intelligent Touch Controller / intelligent Manager III, On/Off
and control of the equipment with the external contacts are
possible through DIII-NET communication.
Installation method Indoor installation
Power supply To be supplied from outside
Rating AC200-240V, 50/60Hz
Applied Standard
Safety standard: IEC730, EMC standard: CISPR22-A (EMI),
CISPR24 (EMS)
Environment for use
Ambient temperature –15 to 60 °C
Ambient humidity 95%RH or less (no condensation)
Environment for storage
Ambient temperature –20 to 60 °C
Ambient humidity 95%RH or less (no condensation)
Voltage specs Maximum current Minimum current
AC200–240V 1.5 A (resistance load) 10mA
DC5–24V 2.0 A (resistance load) 10mA
