8.7.9.9 Checking the Status of an Option Board
The Expander boards pages give information about the basic and option boards connected to the control board. See 7.1 Control
Unit Components for more information on the boards.
For more information on the parameters of the option boards, see 8.8.1 Expander Board Menu.
Procedure
In the System info submenu, find the Expander boards page (6.8.6) with the Browser buttons.
To go to the Expander boards page, push the Menu button Right.
To select the board, use the Browser buttons.
If no board is connected to the slot, the display shows no board.
If a board is connected to a slot but there is no connection, the display shows no conn..
To see the status of the board, push the Menu button Right.
To see the program version of the board, push the Browser button Up or Down.
8.7.9.10 Debug Menu (S6.8.7)
The Debug menu is for advanced users and application designers. Speak to the factory to get instructions, if it is necessary.
8.8 Using the Expander Board Menu
8.8.1 Expander Board Menu
The Expander board menu, that is, the menu for option board information, allows to:
see which option boards are connected to the control board
find and edit the option board parameters.
Table 26: Option Board Parameters (Board OPTA1)
Page
Parameter
Min
Max
Default
Cust
Selections
P7.1.1.1
AI1 mode
1
5
3
1 = 0–20 mA
2 = 4–20 mA
3 = 0–10 V
4 = 2–10 V
5 = –10…+10 V
P7.1.1.2
AI2 mode
1
5
1
See P7.1.1.1
P7.1.1.3
AO1 mode
1
4
1
1 = 0–20 mA
2 = 4–20 mA
3 = 0–10 V
4 = 2–10 V
8.8.2 Examining the Connected Option Boards
Use these instructions to examine the connected option boards.
Procedure
To find the Expander board menu, scroll down in the main menu until the location indication M7 shows on the first line of
the display.
To go to the Expander board menu from the main menu, push the Menu button Right.
To examine the list of connected option boards, use the Browser buttons Up and Down.
To see the information on the option board, push the Menu button Right.
AQ351737303996en-000201 / DPD00888 | 107Danfoss A/S © 2023.09
Using the Control Panel
VACON® NXP IP00 Drive Modules
Operating Guide
