Table 41: Fuse Sizes (Bussmann) for 380–500 V AC, FR13–FR14, 6-pulse
Enclosure
size
Drive
type
Fuses with flush end contact
(metric)
Fuses with flush end contact
(US)
Fuse In
[A]
DC fuses
per drive
AC fuses
per drive
Fuse part nr. (aR)
(AC/DC)
Fuse size
Fuse part nr.
(aR)
Fuse size
FR13
1150
170M6466
3BKN/50
170M6566
3GKN/50
1250
4
6
1300
170M6466
3BKN/50
170M6566
3GKN/50
1250
6
9
1450
170M6466
3BKN/50
170M6566
3GKN/50
1250
6
9
FR14
1770
170M6466
3BKN/50
170M6566
3GKN/50
1250
8
12
2150
170M6466
3BKN/50
170M6566
3GKN/50
1250
8
12
Table 42: Fuse Sizes (Ferraz Shawmut) for 380–500 V AC, FR10–FR12, 6-pulse
Enclo-
sure size
Drive
type
Fuse
size
DIN 43620
DIN 43653 (80
mm)
DIN 43653 (110
mm)
Threaded end
contacts (metric)
Fuse In
[V]
Fuses
per drive
FR10
385
2
2 PV 0700
32 D08A 0700
32 D11A 0700
32 TTF 0700
700
3
460
3
3 PV 1000
33 D08A 1000
33 D11A 1000
33 TTF 1000
1000
3
520
3
3 PV 1000
33 D08A 1000
33 D11A 1000
33 TTF 1000
1000
3
FR11
590
2
2 PV 0700
32 D08A 0700
32 D11A 0700
32 TTF 0700
700
6
650
2
2 PV 0700
32 D08A 0700
32 D11A 0700
32 TTF 0700
700
6
730
2
2 PV 0700
32 D08A 0700
32 D11A 0700
32 TTF 0700
700
6
FR12
820
3
3 PV 1000
33 D08A 1000
33 D11A 1000
33 TTF 1000
1000
6
920
3
3 PV 1000
33 D08A 1000
33 D11A 1000
33 TTF 1000
1000
6
1030
3
3 PV 1000
33 D08A 1000
33 D11A 1000
33 TTF 1000
1000
6
FR12 DC-
link
()
2
2 PV 0700
32 D08A 0700
32 D11A 0700
32 TTF 0700
700
2
In FR12 (12-pulse drive) or in FR12 (6- or 12-pulse) with internal brake, the DC-links between units are connected together. If connected together,
there must be DC-link fuses in DC-minus and DC-plus poles between the units. (In 6-pulse drive without internal brake, DC-links between units are
separate and there is no need for fuses.)
12.4.4 Fuse Sizes for 380–500 V AC, 12-pulse
The aR fuses are thermally rated into switch fuse in 50 °C (122 °F) ambient temperature.
Table 43: Fuse Sizes (Bussmann) for 380–500 V AC, FR10, 12-pulse
Enclo-
sure size
Drive
type
DIN 43620
DIN 43653 (110 mm)
Flush end contacts (met-
ric)
Fuse In
[A]
Fuses
per
drive
aR fuse part
nr.
Fuse
size
aR fuse part
nr.
Fuse
size
aR fuse part
nr.
Fuse size
FR10
385
170M5813
DIN 2
170M5213
2TN/110
170M5463
2BKN/50
700
6
460
170M5813
DIN 2
170M5213
2TN/110
170M5463
2BKN/50
700
6
520
170M5813
DIN 2
170M5213
2TN/110
170M5463
2BKN/50
700
6
