Enclo-
sure size
Drive type
Loadability
(1)
Motor shaft power
Low
High
400 V supply
500 V supply
Rated
continu-
ous cur-
rent I
L
(A)
(2)
Rated
over-
load
current
(A)
Rated
continu-
ous cur-
rent I
H
(A)
Rated
over-
load
current
(A)
Max
current
I
S
Low
over-
load P
(kW)
High
over-
load P
(kW)
Low
over-
load P
(kW)
High
over-
load P
(kW)
NXP0205 5
205
226
170
255
340
110
90
132
110
FR9
NXP0261 5
261
287
205
308
349
132
110
160
132
NXP0300 5
300
330
245
368
444
160
132
200
160
FR10
NXP0385 5
385
424
300
450
540
200
160
250
200
NXP0460 5
460
506
385
578
693
250
200
315
250
NXP0520 5
520
572
460
690
828
250
250
355
315
FR11
NXP0590 5
590
649
520
780
936
315
250
400
355
NXP0650 5
650
715
590
885
1062
355
315
450
400
NXP0730 5
730
803
650
975
1170
400
355
500
450
FR12
NXP0820 5
820
902
730
1095
1314
450
400
560
500
NXP0920 5
920
1012
820
1230
1476
500
450
630
560
NXP1030 5
1030
1133
920
1380
1656
560
500
710
630
FR13
NXP1150 5
1150
1265
1030
1545
1620
630
560
800
710
NXP1300 5
1300
1430
1150
1725
2079
710
630
900
800
NXP1450 5
1450
1595
1300
1950
2484
800
710
1000
900
FR14
NXP1770 5
1770
1947
1600
2400
2880
1000
900
1200
1100
NXP2150 5
2150
2365
1940
2910
3492
1200
1100
1500
1300
1
See
12.9.1 Overload Capability
2
The currents in given ambient temperatures are achieved only when the switching frequency is the same or smaller than the factory default.
12.9.3 Power Ratings for Mains Voltage 500–690 V
Table 64: Power Ratings in Mains 500–690 V, 50/60 Hz, 3~
Enclo-
sure size
Drive type
Loadability
(1)
Motor shaft power
Low
High
690 V supply
575 V supply
Rated
continu-
ous cur-
rent I
L
(A)
(2)
Rated
overloa
d cur-
rent (A)
Rated
continu-
ous cur-
rent I
H
(A)
50 %
over-
load
current
(A)
Max
current
I
S
Low
over-
load P
(kW)
High
over-
load P
(kW)
Low
over-
load P
(kW)
High
over-
load P
(kW)
FR8
NXP0062 6
62
68
52
78
104
55
45
60
50
NXP0080 6
80
88
62
93
124
75
55
75
60
AQ351737303996en-000201 / DPD00888 | 145Danfoss A/S © 2023.09
