Enclosure size
Drive type
Temperature rating
(1)
Internal cable/phase [mm
2
]
FR10
NXP 0385
90 °C (194 °F)
2*70
70 °C (158 °F)
2*95
NXP 0460-0520
90 °C (194 °F)
2*95
70 °C (158 °F)
2*120
FR11
NXP 0590-0730
90 °C (194 °F)
2*2*70
70 °C (158 °F)
2*2*95
FR12
NXP 0820-1030
90 °C (194 °F)
2*2*95
70 °C (158 °F)
2*2*120
1
70C PVC/90C XLPE Cu cable
Table 35: Cable Sizes for 380–500 V AC, FR13–FR14
Enclosure
size
Drive type
Busbar size
NFE-INU
[mm]
Busbar size/
phase
(1)
(AC
choke–NFE)
[mm]
Cable size/
phase (AC
choke–NFE)
[mm]
Remarks
FR13
NXP 1150 5
60*10
40*6
2*150
-
NXP 1300-1450
80*10
40*6
2*120
-
FR14
NXP 1770 5
60*10
40*6
2*120
Routing: Use symmetrical construction. See
pictures in 5.4 Cabinet Requirements for
FR13–FR14.
NXP 2150 5
2*150
1
Rigid copper connection
12.4.2 Busbar and Terminal Dimensions for 380–500 V AC
Table 36: Terminal Dimensions for 380–500 V AC, FR8–FR9
Enclosure size
Drive type
Mains terminal [mm
2
]
Grounding terminal [mm
2
]
FR8
NXP 0140
25–95 Cu/Al
6–95
NXP 0168 –0205
95–185 Cu/Al
FR9
NXP 0261–0300
95–185 Cu/Al
6–95
Table 37: Busbar Dimensions for 380–500 V AC, FR8–FR12
Enclosure size
Drive type
Cu busbar size
Busbars total
FR10
NXP 0385
30*6 mm
3
NXP 0460–0520
40*6 mm
3
FR11
NXP 0590–0730
30*6 mm
6
FR12
NXP 0820–1030
40*6 mm
6
AQ351737303996en-000201 / DPD00888 | 133Danfoss A/S © 2023.09
Specifications
VACON® NXP IP00 Drive Modules
Operating Guide
