8 Using the Control Panel
8.1 Navigating on the Control Panel
The data of the AC drive is in menus and submenus. Follow these instructions to navigate in the menu structure on the control
panel.
Procedure
To move between the menus, use the Browser buttons Up and Down on the keypad.
To go into a group or an item, push the Menu button Right.
To go back to the previous level, push the Menu button Left.
The display shows the current location in the menu, for example S6.3.2. The display also shows the name of the
group or item in the current location.
READY
RUN
Keypad
A
B
C
e30bf980.10
Monitor
V1 V1
Illustration 71: Navigation Items on the Control Panel
A
The location on the menu
B
The description (name of the page)
C
The number of items that are available or
the item value.
8.2 Using the Monitoring Menu (M1)
Follow these instructions to monitor the actual values of the parameters and signals.
The values cannot be changed in the Monitoring menu. To change the values of parameters, see 8.3.2 Selecting Values or 8.3.3
Editing the Values Digit by Digit.
Procedure
To find the Monitoring menu, scroll down in the main menu until the location indication M1 shows on the first line of the
display.
e30bg022.10
READY
RUN
Monitor
Keypad
V1 V14
To go to the Monitoring menu from the main menu, push the Menu button Right.
To scroll through the menu, push the Browser buttons Up and Down.
8.2.1 Monitored Values
The monitored values have the indication V#.#. The values update each 0.3 s.
AQ351737303996en-000201 / DPD0088884 | Danfoss A/S © 2023.09
Using the Control Panel
VACON® NXP IP00 Drive Modules
Operating Guide
