Danfoss VACON NXP IP00 - Dimensions for Inverter Unit (FR13;FR14)

239
(9.41)
1030
(40.55)
952
(37.48)
116
(4.57)
211
(8.31)
U
+ –
V
W
65
(2.56)
65
(2.56)
153
(6.02)
140
(5.51)
54
(2.13)
341
(13.43)
371
(14.61)
304
(11.97)
244
(9.61)
85
(3.35)
116
(4.57)
Ø13
(0.51)
Ø13
(0.51)
Ø26
(1.02)
Ø9.5
(0.37)
R4.5
R2.5
R4
R10
e30bk651.10
Illustration 82: Dimensions, 3 NFE Units
12.3.4.7 Dimensions for Inverter Unit (FR13/FR14)
AQ351737303996en-000201 / DPD00888 | 127Danfoss A/S © 2023.09
Specifications
VACON® NXP IP00 Drive Modules
Operating Guide
