The option board abbreviations:
A = Basic I/O board
B = Expander I/O board
C = Special board
D = Fieldbus board
E = Fieldbus board
For example, E3 = PROFIBUS DP
The optional codes. See full list of option codes in the VACON
®
NXP Selection Guide.
3.4 Enclosure Sizes
Example
The codes for nominal current and nominal mains voltage are part of the type code (see
3.3 Description of the Type Code) on the
package label (see 3.2 Package Label). Use these values to find out the enclosure size of the AC drive from the table.
In the example "NXP03855-A0N0SSG-A1A20000E3", the code for nominal current is 0385 and the code for nominal mains voltage is
5.
Table 4: Enclosure Sizes
AQ351737303996en-000201 / DPD00888 | 19Danfoss A/S © 2023.09
