Table 44: Fuse Sizes (Bussmann) for 380–500 V AC, FR13–FR14, 12-pulse
Enclosure
size
Drive
type
Fuses with flush end contact
(metric)
Fuses with flush end contact
(US)
Fuse In
[A]
Fuses per
drive
Fuses per
drive
Fuse part nr. (aR)
(AC/DC)
Fuse size
Fuse part nr.
(aR)
Fuse size
FR13
1150
170M6466
3BKN/50
170M6566
3GKN/50
1250
4
6
1300
170M6466
3BKN/50
170M6566
3GKN/50
1250
6
12
1450
170M6466
3BKN/50
170M6566
3GKN/50
1250
6
12
FR14
1770
170M6466
3BKN/50
170M6566
3GKN/50
1250
8
12
2150
170M6466
3BKN/50
170M6566
3GKN/50
1250
8
12
Table 45: Fuse Sizes (Ferraz Shawmut) for 380–500 V AC, FR10–FR12, 12-pulse
Enclo-
sure size
Drive
type
Fuse
size
DIN 43620
DIN 43653 (80
mm)
DIN 43653
(110 mm)
Threaded end
contacts (metric)
Fuse In
[V]
Fuses per
drive
FR10
385
2
2 PV 0450
32 D08A 0450
32 D11A 0450
32 TTF 0450
450
6
460
2
2 PV 0450
32 D08A 0450
32 D11A 0450
32 TTF 0450
450
6
520
2
2 PV 0450
32 D08A 0450
32 D11A 0450
32 TTF 0450
450
6
12.4.5 Internal Cable Sizes for 525–690 V AC
Table 46: Cable Sizes for 525–690 V AC, FR8–FR12
Enclosure size
Drive type
Temperature rating
(1)
Internal cable/phase [mm
2
]
FR8
NXP 0062
90 °C (194 °F)
25
70 °C (158 °F)
35
NXP 0080
90 °C (194 °F)
25
70 °C (158 °F)
35
NXP 0100
90 °C (194 °F)
35
70 °C (158 °F)
50
FR9
NXP 0125
90 °C (194 °F)
50
70 °C (158 °F)
70
NXP 0144
90 °C (194 °F)
70
70 °C (158 °F)
95
NXP 0170
90 °C (194 °F)
70
70 °C (158 °F)
95
NXP 0208
90 °C (194 °F)
95
70 °C (158 °F)
120
FR10
NXP 0261–0416
90 °C (194 °F)
2*70
70 °C (158 °F)
2*95
