Table 61: Cable Stripping Lengths [in]
Enclosure size
A1
B1
C1
D1
A2
B2
C2
D2
FR8, 0140
FR8, 0168–0205
0.91
1.10
9.45
9.45
0.91
1.10
9.45
9.45
0.91
1.10
9.45
9.45
0.91
1.10
9.45
9.45
FR9
1.10
11.61
1.10
11.61
1.10
11.61
1.10
11.61
12.7 Tightening Torques for Cover Screws
Enclosure size and class
Cable cover screws (Nm)
Screws on the cover of the AC drive (Nm)
FR8
0.8 Nm
(1)
0.8
FR9
0.8
0.8
1
The cover of the power unit.
12.8 Tightening Torques of the Terminals
Table 62: Tightening Torques of the Mains and Motor Terminals
Enclosure size
Drive type
Tightening torque (Nm)
Tightening torque (in-lb)
FR8
0140 5
20
177.01
0168 5–0205 5
40
354.03
FR9
0261 5–0300 5
0125 6–0208 6
40/22
(1)
354.03/194.72
(1)
FR10–FR14
0385 5–1450 5
40
(2)
354.03
(2)
FR10–FR14
0261 6–1180 6
40
(2)
354.03
(2)
1
Tightening torque of terminal connection to the isolative base in Nm/in-lb. NOTE: This value is needed only if the motor connection is made direct-
ly to the AC drive (no devices between AC drive and motor).
2
Apply counter torque to the nut on the other side of the terminal when tightening or loosening the terminal screw to avoid damage to the termi-
nal
12.9 Power Ratings
12.9.1 Overload Capability
The low overload means that if 110% of the continuous current (I
L
) is required for 1 minute every 10 minutes, the remaining 9
minutes must be approximately 98% of I
L
or less. This is to make sure that the output RMS current is not more than I
L
during the
duty cycle.
AQ351737303996en-000201 / DPD00888 | 143Danfoss A/S © 2023.09
Specifications
VACON® NXP IP00 Drive Modules
Operating Guide

Danfoss VACON NXP IP00 Specifications
