RS20i Installation and Operating Guide Page E-11
Appendix E. Remote Command API Document #: 9301H52900 Ver. 1.02
14. Pro Logic II/IIx Mode
Selects Pro Logic II or Pro Logic IIx mode to Pro Logic, Music, Game or Dolby Digital
EX. The Pro Logic II/IIx mode selection is in affect only when the Post Processing Mode
(DECODERPOST) is set for Pro Logic II or Pro Logic IIx.
Command: @DPL2MODE [value]<cr>
Operation
Response: DPL2MODE [value]<CR>
Read/Write
Parameters
[value] Selection
0
Pro Logic (1)
2
Music
3
Movie
4
Dolby Digital EX
(2)
Notes:
1. Pro Logic can only be selected with Pro Logic II (speaker configuration without
LB/RB).
2. Pro Logic EX can only be selected with Pro Logic IIx (speaker configuration with
LB/RB).
Three additional controls are available only for use with Pro Logic IIx Music mode
(DPL2MODE 1). Those are Dimension, Center Width, and Panorama. See commands
DPL2DIM, DPL2CW, and DPL2PANO for additional details.
15. Dimension for Pro Logic IIx Music Mode
The Dimension control is used with Pro Logic IIx music mode to adjust the sound field.
Command: @DPL2DIM [DIM]<cr>
Operation
Response: DPL2DIM DIM<CR>
Read/Write
