Datasat RS20i - 16. Center Width for Pro Logic IIx Music Mode; 17. Panorama for Pro Logic IIx Music Mode

RS20i Installation and Operating Guide Page E-12
Appendix E. Remote Command API Document #: 9301H52900 Ver. 1.02
Parameters:
DIM Selection
7
+ 7 Sound field towards
6
+ 6 the rear
5
+5
4
+4
⇑
3
+3
2
+2
1
+1
0
0
-1
-1
-2
-2
-3
-3
-4
-4
⇓
-5
-5
-6
- 6 Sound field towards
-7
- 7 the front
16. Center Width for Pro Logic IIx Music Mode
The Center Width control works with Pro Logic IIx music.
Command: @DPL2CW [cw]<cr>
Response: DPL2CW cw<CR>
Read/Write
Parameters:
cw Selection
0
0 (Off, no balance applied)
1
1
2
2
3
3 (Neutral)
4
4
5
5
6
6
7
7 Phantom Center
17. Panorama for Pro Logic IIx Music Mode
Enable or Disable the Panorama setting used with Pro Logic IIx music mode.
Command: @DPL2PANO [pano]<cr>
Response: DPL2PANO pano <CR>
Read/Write
Parameters:
pano Selection
0
0 Panorama off
1
1 Panorama on
