RS20i Installation and Operating Guide Page E-16
Appendix E. Remote Command API Document #: 9301H52900 Ver. 1.02
Setup Information
These commands return information regarding the current setup of the RS20i in terms of
what inputs and automation macros have been defined.
28. List Input Names
The RS20i may have up to 20 user-defined Input names. This command returns a
comma delimited string with all Input names assigned in the RS20i.
Command: @INPUTNAMES <cr>
Operation
Response: INPUTNAMES input1,[input2],[input3],…<CR>
Read
Parameters
input1-input20
Input names. There may be 1 to 20 Input names. Each
name will have a comma to separate it from the next
name. Spaces may be included in the Input names.
29. List Macro Names
The RS20i may have several user-defined macros. This command returns a comma
delimited string with all macro definitions in the RS20i.
Command: @MACRONAMES <cr>
Operation
Response: MACRONAMES [m1],[m2],[m3],…<CR>
Read
Parameters
m1-mx Macro names. Each name will have a comma to separate it from the
next name. Spaces may be included within the macro names. This will
be empty if there are no macros defined in the RS20i.
30. List EQ Setup Names
The RS20i may up to 20 different EQ sets stored. This command returns a comma
delimited string with all EQ setup names.
Command: @EQNAMES<cr>
Operation
Response: EQNAMES e1,[e2],[e3],…<CR>
Read
Parameters
e1-ex EQ set names. Each name will have a comma to separate it from the
next name. Spaces may be included within the macro names.
General Commands
31. System Information
Returns system versions and MAC address
Command: @SYSTEM <cr>
Operation
Response: VER<space>version<LF>
VERDATE<space>date<LF>
MAC<space>mac address<CR>
Read
Parameters
version
Software version number
date
Software date/time
mac address
RS20i 20 MAC address
